Feature:
1.Max intermittent pressure up to 420 bar (6090 psi) and continuous operating pressure up to 350 bar (5075 psi)
2.Thanks to low weight pistons and a compact design of the rotating parts, the F11 tolerates very high speeds, up to 14000 rpm
3.CETOP, ISO, SAW and SAE versions.
4.The laminated piston ring offers important advantages such as unbeatable efficiency and thermal shock resistance
5.High allowable speeds and operating pressures means high output power
6.The unique piston locking, timing gear and bearing set-up as well as the limited number of parts
add up to a very robust design with long service life and, above all, proven reliability.
7.The 40° angle between shaft and cylinder barrel allows for a very compact, lightweight motor/ pump.
8.Small envelop size and a high power-to-weight ratio
9.The motor version has highly engineered valve plates for high speed and low noise
10.The pump version has highly engineered valve plates for increased self priming speed and low
noise, available with left and right hand rotation.
11.The F11's and F12's have a simple and straight-forward design with very few moving parts,
making them very reliable motors/pumps.
12.Our unique timing gear design synchronizes shaft and cylinder barrel, making the F11/F12 very
tolerant to high 'G' forces and torsional vibrations.
13.Heavy duty roller bearings permit substantial external axial and radial shaft loads.
| Specifications | Series F11/F12 | ||||||||||
| Frame size | F11-5 | -10 | -14 | -19 | F12-30 | -40 | -60 | -80 | -110 | F11-150 | F11-250 |
| Displacement [cm3/rev] | 4.9 | 9.8 | 14.3 | 19.0 | 30.0 | 40.0 | 59.8 | 80.4 | 110.1 | 150 | 242 |
| [cu in/rev] | 0.30 | 0.60 | 0.87 | 1.16 | 1.83 | 2.44 | 3.65 | 4.91 | 6.72 | 9.15 | 14.8 |
| Operating pressure | |||||||||||
| max intermittent)[bar] | 420------------------------------------------420 | 480------------------------------------480 | 420 | 420 | |||||||
| [psi] | 6000----------------------------------------6000 | 7000-----------------------------------------------------7000 | 6000 | 6000 | |||||||
| max continuous [bar] | 350----------------------------350 | 420------------------------------------420 | 350 | 350 | |||||||
| [psi] | 5000----------------------------------------5000 | 6000-----------------------------------------------------6000 | 5000 | 5000 | |||||||
| Motor operating speed [rpm] | |||||||||||
| max intermittent¹) | 1200011000 | 10000 | 9000 | 7100 | 6400 | 5600 | 5200 | 4700 | 3000 | 2700 | |
| max continuous | 108009900 | 9000 | 8100 | 5 600 5 000 4 300 4 000 | 3600 | 2600 | 2400 | ||||
| min continuous | 50…… | ……- | 50 | ||||||||
| Max pump selfpriming speed²) | |||||||||||
| L or R function; max [rpm] | 4600 | 4200 | 3900 | 3500 | 3150 | 2870 | 2500 | 2300 | 2290 | 1700 | 1500 |
| Motor input flow | |||||||||||
| max intermittent¹)[l/min] | 58 | 108 | 143 | 171 | 213 | 256 | 335 | 418 | 517 | 450 | 650 |
| [gpm] | 15.3 | 28.5 | 37.8 | 45.2 | 56.3 | 67.6 | 88.5 | 110.4 | 136.6 | 119.0 | 172.8 |
| max continuous [l/min] | 52 | 97 | 128 | 153 | 168 | 200 | 257 | 322 | 396 | 390 | 580 |
| [gpm] | 13.7 | 25.6 | 33.8 | 40.4 | 44.4 | 52.8 | 67.9 | 85.1 | 104.6 | 103.0 | 153.6 |
| Main circuit temp.3, max [C] | 80 | 80 | 80 | 80 | 80 | 80 | 80 | 80 | 80 | 80 | 80 |
| [°F | 175 | 175 | 175 | 175 | 175 | 175 | 175 | 175 | 175 | 175 | 175 |
| min [℃] | 35 | -35 | -30 | -35 | 35-----------------------------------------------------35…………………………………- -35 | -35 | -35 | ||||
| [°F | -31 | -31 | -22 | -31 | -31------------------------------------------35 | -31 | -31 | ||||
| Mass moment of inertia | |||||||||||
| (x10-3)[kg m2] | 0.16 | 0.39 | 0.42 | 1.1 | 1.7 | 2.9 | 5 | 8.4 | 11.2 | 40 | 46 |
| (x10-2)[lbft2] | 0.38 | 0.92 | 1.00 | 2.61 | 4.03 | 6.88 | 11.86 | 19.93 | 26.58 | 94.92 | 109.16 |
| Weight [kg] | 5 | 7.5 | 8.3 | 11 | 12 | 16.5 | 21 | 26 | 36 | 70 | 77 |
| [Ilb] | 11 | 16.5 | 18.8 | 24 | 26 | 36 | 46 | 57 | 79 | 154 | 170 |
