Fixed Displacement Vane pump SQP

Highlights and Innovations

1. Adopt V series composition vane pump core, making the application flexible by its complete interchangeable advantage.

2. Adopt the structure of pulsation attenuation, dramatically reducing the pulsation of pressure with lower noise.

3. Adopt the designing with thick pump casing, making the pump with stronger strength, stronger vibration resistance and better performance of silencing.

PDF Download

Feature
Model code
Related Products

Feature:

1. Cartridge kits are entirely similar to those of Vickers satable V series pumps ,which can be interechanged wtih cartridge kits of SQP series .

2.New configuration design gets an excellent performance in restraining plusing and nosie.

3.Strengthened pump housing design offers a better anti-vibration ability ,which effect the remarkable nosie.

Product	SQP
Application	plastic machinery, forging machinery, machine tool industry and engineering machinery,
Displacement/Size	SQP1:2,3,4,5,6,7,8,9,10,11,12,14 SQP2:10,11,12,14,15,17,19,21S QP3:21,25,30,32,35,38,45 SQP4:42,45,50,57,60,66,75
Control types	fixed displacement pumps
Max pressure	17.2 MPa
Max Speed	1800rpm
Max Flow	/
Material	Cast Iron
Guarantee Period	1 Year
Customization or not	/

Model Code
Framesize	Code	GeometricDisplacementml/r	Max.pressureMPa	Max.Speedr/min	Min.Speedr/min
SQP1	2	7.5	13.8	1800	600
	3	10.2	13.8
	4	12.8	17.2
	5	16.7
	6	19.2
	7	22.9
	8	26.2
	9	28.8
	10	31.0
	11	35.0
	12	37.9	15.7
	14	44.2	13.8
SQP2	10	32.5	17.2	1800	600
	12	38.3
	14	43.3
	15	46.7
	17	52.5
	19	59.2
	21	65.0
SQP3	21	66.7	17.2	1800	600
	25	79.2
	30	95.0
	32	100
	35	109
	38	118
	45	156
SQP4	42	134	17.2	1800	600
	45	140
	50	156
	57	178
	60	189
	66	207
	75	237
