Fitur:
1). Kelompok rotari berkinerja tinggi dengan area kontrol bola yang terbukti menawarkan keunggulan berikut.
2). Penyatuan otomatis, kecepatan peripheral rendah, efisiensi tinggi.
3). Umur pemakaian panjang, bearing gulir yang kokoh.
4). Poros penggerak akan menopang beban radial.
5). Tingkat kebisingan rendah.
6). Bearing gulung bertugas tinggi untuk operasi tekanan tinggi secara intermiten. Untuk tugas berkelanjutan, bearing hidrostatis tersedia.
| Displacement | Vgmax m | l/r 20.5 | 28.1 | 40.1 | 54.8 | 58.8 | 80 | 78 | 107 | 117 | 160 | 250 | 355 | 500 | ||
| Vgmax | ml/menit | 0 | 8.1 | 0 | 15.8 | 0 | 23.1 | 0 | 30.8 | 0 | 46.2 | 0 | 0 | 0 | ||
| 0.09MPa¹ | Nmax0.09 | r/menit | 3800 | 2800 | 3200 | 2360 | 2850 | 2120 | 2540 | 1900 | 2240 | 1650 | 1400 | 1250 | 1120 | |
| Kecepatan maks. | 0.1MPa¹ | Nmax0.1 | r/menit | 4100 | 3000 | 3400 | 2500 | 3000 | 2240 | 2700 | 2000 | 2360 | 1750 | 1500 | 1320 | 1200 |
| 0.15MPa¹ | Nmax0.15 | r/menit | 4750 | 3600 | 3750 | 3000 | 3350 | 2750 | 3000 | 2450 | 2650 | 2100 | 1850 | 1650 | 1500 | |
| Nmax0.09 | Qmax0.09 | L/menit | 76 | 76 | 124 | 125 | 161 | 164 | 192 | 197 | 254 | 256 | 340 | 430 | 543 | |
| Debit.maks² | Nmax0.1 | Qmax0.1 | L/menit | 82 | 82 | 132 | 133 | 170 | 174 | 204 | 208 | 267 | 271 | 364 | 455 | 582 |
| Nmax0.15 | Qmax0.15 | L/menit | 94 | 98 | 146 | 160 | 190 | 213 | 227 | 254 | 300 | 326 | 449 | 568 | 728 | |
| Qmax0.09 | Pmax0.09 | kW | 45 | 46 | 75 | 75 | 97 | 99 | 116 | 119 | 153 | 154 | 204 | 259 | 326 | |
| Max.power | Qmax0.1 | Pmax0.1 | kW | 49 | 49 | 80 | 80 | 102 | 105 | 123 | 125 | 161 | 163 | 218 | 273 | 350 |
| (△,=35MPa) | Qmax0.15 | Pmax0.15 | kW | 57 | 59 | 88 | 96 | 114 | 128 | 136 | 153 | 181 | 196 | 270 | 342 | 437 |
| Aliran Q² | NE=1450r/menit | L/menit | 28.8 | 39.5 | 56.4 | 77.1 | 82.3 | 112.5 | 109.7 | 150.5 | 164.6 | 225 | - | |||
| Daya | ||||||||||||||||
| P(△.=35MPa)NE=1450r/menit | kW | 17 | 24 | 34 | 46 | 50 | 68 | 66 | 91 | 99 | 135 | |||||
| Torsi | Vgmax | Nm/10MPa | 32.6 | 44.6 | 63.7 | 87 | 93.2 | 127.5 | 124 | 169.7 | 186 | 254 | 397.5 | 564.5 | 795 | |
| M(△p=10MPa)Vgmin | Nm/10MPa | - | 12.9 | 25.1 | 36.8 | - | 49 | 73.5 | - | |||||||
| P(△p=35MPa)Vgmax | Nm | 114 | 156 | 223 | 305 | 326 | 446 | 431 | 594 | 651 | 88.9 | 1391 | 1975 | 2782 | ||
| torsi maksimum | Vgmin | Nm | 45 | 88 | 129 | - | 171 | 257 | ||||||||
| Momen | kgm² | 0.0017 | 0.0017 | 0.00520.0052 | 0.01090.0109 | 0.01670.0167 | 0.0322 | 0.032 | 20.088 | 0.160 | 00.270 | |||||
| Berat | kg | 19 | 19 | 28 | 28 | 44 | 44 | 53 | 53 | 76 | 76 | 105 | 165 | 245 | ||
